Providing 21st Century Technology Solutions Since 2000

Installation, maintenence and support of:

  • VoIP provider platforms, Asterisk/IP-PBX/VoIP, including global consulting, remote configuraton and training, as well as local services; support and installation.*
  • Networks; WiFi, LAN, WAN, Wired, from smaller home networks to large corporate or campus wide networks supported locally*.
  • Installation and upgrades of High Definition Closed Circuit TV Systems; CCTV, MATV, CATV, for condominiums, hotels, apartments and campuses.
  • Installation and upgrades of High Definition Security Camera Systems, installations upgrades and repairs locally*

* Our local services area varies based on products supported, but for the most part includes many areas in the stares of: Guanajuato, Queretaro, Jalisco, and Nayarit. Please call for more information related to the product or service you seek.

IP PBX, VoIP & Asterisk

We offer solutions and support for IP PBX Phone systems including:

  • IP PBX, VoIP and Asterisk, FreePBX, Issabel consulting services (Worldwide).
  • Support for VoIP phone systems using Polycom, Cisco, Linksys, Sipura, Grandstream, Yealink, and other SIP and IAX based phone systems (Worldwide).
  • Virtual IP PBX Systems in the Cloud (Worldwide).
  • Remote Configuration & Support for VoIP Server Platforms. (Worldwide).
  • Remote configuration, Support, Upgrades, Expansion, Enhancements for Asterisk, Elastix, 3CX, FreePBX, PBX in a Flash (Localy or Worldwide).
  • Google Voice Integration for a Free Incoming USA Number and Free Unlimited USA and Canada Calling.
  • Termination; Calls to Most Any Country in the World, at the Most Competitive Rates.
  • Origination; DID, or a Real Phone Number from Most Any Country in the World.
  • Through GoogleVoicePhone.com we ofer the original GoogleVoicePhone Product to connect an analog telephone adapter to Google Voice.
  • Through IceVoIP.com we offer expanded services for Google Voice including Google Voice MultiPhone and Google Voice Phone+.

At Teknogeekz we have been doing VoIP since 2000, when VoIP was new. We have the expertise and experience to make your VoIP project or system a success.

Phone System Recordings

Custom voice recordings for your telephone system, PBX or IVR:

  • Custom recordings in English.
  • Recordings for complex interactive menus.
  • US Native English speaking voice with neutral accent.
  • Files optimized for use on phone systems.
  • Files in the format you request.
  • Spanish language also available.
  • Translations available.

Download the sample files here (use right click and "save as" to save the file):
MS WAV Ulaw, typical phone system quality
MS WAV Signed 32bit, high quality

VoIP Platforms for ITSPs & ISPs

We offer solutions and support for IP PBX Phone systems including:

  • Services for Internet Service Providers that want to offer VoIP phone service, without installing and maintaining their own platform (Mexico).
  • Installations of VoIP platforms for service providers (Worldwide).

At Teknogeekz we have been doing VoIP since 2000, when VoIP was new. We have the expertise and experience to make your VoIP project or system a success.

Networking, LAN, WAN & WiFi

WiFi, LAN, WAN, and networking support whether in home or on a large campus:

  • Support for you LAN, or network in Home or office.
  • High speed, long range wireless networks.
  • Secure remote access to your home LAN or network over the Internet by way of a private VPN.
  • Remote configuration of devices on your LAN or network
  • Linux based servers for file sharing, web server, or other, tailored to your needs.
  • network troubleshooting.
  • Broadband connection troubleshooting.
  • Unique custom solutions.

Closed Circuit TV Systems

Closed Circuit; CCTV, CATV, MATV. Distribution for condominiums, hotels and apartments.

  • Installations of CCTV and MATV systems up to full HD 1080P.
  • Upgrade Standard Defintion (SD) systems to (HD).
  • Compatible with sources from satellite, Cable, Terrestrial Digital Television, DVD or Internet Streams.
  • Integration with security camera systems, to see your security cameras on your closed circuit system.
  • Systems that require no decoder box.
  • Unique custom solutions.

Security Cameras & Systems

Advanced security systems incorporating the latested HD camera and Digital Video Recording (DVR) systems:

  • For monitoring of home or office remotely.
  • HD 1080P full high definition.
  • Wireless cameras, wireless DVRs.
  • For home, office or campus wide.
  • Unique custom solutions.

Our Web Properties

We have a number of web properties which include:

  • TecnologiaDeLeon.com -this same site in Spanish.
  • SanMiguelTel.com -offering alternative Voice (telephone) solutions and antique telephones.
  • GoogleVoicePhone.com -offering basic USA/Canada VoIP service based on Google Voice, but connects to a standard telephone.
  • IceVoIP.com -offering enhanced VoIP phone service based on Google Voice with flate rate international calling and USA/Canada 911.

Rural Telephony

Rural Telephony Solutions for those living out of the area of tradtional services.

  • Fixed phone via GSM Gateway (Fixed GSM/4G Terminal).
  • VoIP local line for those who have an existing broadband connection.

Useful Projects

These are some projects that we have created for our own use. We hope that others may find them useful. Divider

AirScan (previously called PHPScan) is something we created borrowing from the phpSANE GUI and the the Bastel site. Halo Magic Scanner Mustek s400w, ION Air Copy, ION AirCopy E-Post Edition, Century CPS A4, iScan Air, Transcription Patri Kun A4 Wi-Fi Portable Scanner,転写パットリくん A4 Wi-Fiポータブルスキャナー
AirScan should be considered alternate software of supplemental software for your Portable WiFi Scanner. it should work with any of the following scanners, however we have only tested it on ION AirCopy and Halo Magic Scanner:

  • ION AirCopy
  • ION AirCopy E-Post Edition
  • Halo Magic Scanner
  • Mustek iScan Air / S400W
  • Century CPS-A4WF
  • Transcription Patri Kun A4 Wi-Fi Portable Scanner
  • 転写パットリくん A4 Wi-Fiポータブルスキャナー
To use this you will need:
  • One of the aforementioned scanners
  • A Linux x86 or x86_64 computer as a host
  • A web server with PHP support
  • download the s400w Linux executable here and add it to the html folder where you install AirScan.
With AirScan, it is best that the scanner connects to a dedicated Wifi connection on the host, giving you access to your small portable sheet feed scanner from any device on your network that has a web browser; tablet, smartphone, smart TV or computer. The result is a highly portable, wireless, battery powered, network scanning solution.

AirScan might also be useful for an office environment where occassional scanning is needed but does not warrant a dedicated scanner at each workstation. It allows passing the scanner as needed from cubicle to cubicle.

To use AirScan, no modification is required to the scanner and it will still work with the Windows, Mac, Android or iOS apps when you are on the road away from your AirScan host. One advantage of AirScan over the bundled software, is that you will not need to disconnect your WiFi from your Internet connection to connect to the scanner. You can have both Internet and scanning on the same connection by way of the host computer, and all devices on the network have access to the scanner. For OSX, iOS. Windows and Android users, this gets around the issue of bundled software compatibility, as you only need a web browser and connect to your existing network to use it.

AirScan uses a web interface via Apache or other web server with PHP on your Linux x86 or x86_64 host machine, making it into a scan server. You need a host with a wired or wireless connection to your LAN, then a dedicated wireless connection for the scanner. Now any device connected to your LAN can scan wirelessly with the portable sheet feed scanner, while maintaining the Internet connection.

All files are saved to the host automatically once scanned, and you can simply share the folder from the web server, or use SAMBA, NFS or even install a web based file manager to make all scans available to all computers. You can also save the image to a local device with "right click" or "touch hold" and "save image as" or "download image" when the scan is completed and displayed on screen.

Now you can move the scanner to anywhere you have the wifi connection to the host available, more than one host if you like, or connect through a repeater to expand the range.

The interface will load in English or Spanish based on browser preference. You can easily add other languages to on the lang.php file. Currently if your browser is not set for English or Spanish, you will get the English interface. We welcome language file and other contributions!

If you want to use this, you will find the comments in the config.inc.php file may be useful. You will need to identify the default IP address of your scanner and configure your host machine to always connect to the scanner.

There are some options added for ImageMagick in the config.inc.php file as it seems that The ION AirCopy leaves black space around some images while the Halo Magic Scanner does not. ImageMagick was added to crop off this black space and has proven problematic. be sure to set the location of the "convert" or "magick" binary in config.inc.php.

This image walks you through the AirScan Scanning Process. The image below shows version 6.0. In the latest 6.2 Free version, there are no image rotate, flip nor print options. Version 6.2 paid version now has additional options not shown below, in addition to rotate options as seen below. Click the image to see it larger. AirScan formerly PHPScan for ION AirCopy, Century CPS, Halo Magic Scanner, Mustek iScan Air s400w

Download Here Version 6.2Free - 20180914
Licensed as TeknoGeekzWare; download, and use it for personal use, free of charge, but please consider upgrading should you find it useful. Modification of free version is prohibited. Commercial use, or modification requires the use of the paid version. Redistibution in any form is prohibited of any and all versions, modified or unmodified.

The Bastel site has source code for the Linux and Windows excutables, as well as pre-compiled Linux and Windows executables, however I can not guarantee that the PHP is OS agnostic, should you want to try to run this on Windows, Raspberry Pi, or OSX.

Thanks to Bastel and the phpSANE project for providing the foundation to work from. It made it a lot easier than starting from scratch.

Divider

GVSIP Account Installer is a simple HTML interface that allows you to easily add a GVSIP account to any GVSIP equipped asterisk server. It requires only a web server and php running on the asterisk machine. No database required.

GVSIP commonly refers to Google's implementation of SIP. GVSIP-NAF is here and there are other forks now appearing as well as some installers for FreePBX and IncrediblePBX.

You Will need any asterisk server running a GVSIP-NAF variant of asterisk. Make a backup of your /etc/asterisk directory before testing this!

Users of Vanilla asterisk may need to forgo some display features in the status after the account is generated or do some editing so they work, as well as additional permissions tweaking.

There are installers to use GVSIP NAF with Free PBX which I recommend over the Incredible PBX.

This version of GVSIP Account Installer is working basic, early version. We do not update it generally , however if you find a bug, please let us know so we can fix it. We have an advanced version that allows a user to login and see their extension(s) and trunk registration status. We can make this advanced version available for a fee.

By default GVSIP Account Installer creates 2 chan_SIP extensions for user registrations, and one pjsip trunk to register to Google. The user must generate their Auth Token on the Google Developers Playground. The account is generated with GV Phone number and auth token.

Files are generated and includes are then postpended to pjsip.conf, pjsip_custom or pjsip_custom_post.conf, and sip.conf, sip_custom.conf or sip_custom_post.conf respectively. You can change what files are postpended in the security.conf file as well as customize the options there and in the template.sh, including any SIP options that may be relevant for your release of GVSIP.

After the files are created, it reloads asterisk to activate them then displays SIP extension stats and PJSIP trunk staus.

If you use our included custom contexts, there will be no additional outbound nor inbound routing required in the extensions.conf, or GUI. All users will dial out on their own trunk and their extensions will ring when their GV number is called. There will be no extension to extension calling, and dialing *97 or the users own GV Number will take the user to GV voice mail.

If you want to allow your users to login and see stats after account generation, we have the advanced version with user logins available for purchase. If you migrate to the advanced version from this one, you will need to manually edit the pjsip_.conf files or regenerate them in the advanced GUI.

Download GVSIP Account Installer here.
